Mimo 7" Capacitive Touch, VESA-75mm pattern Display, USB (UM-760CF)

1,081.00 NIS
| /
description

7” Multi-Point Capacitive Touch with Vesa-75mm pattern Display

First, Mimo introduced the world’s first ever capacitive touchscreen USB 7” display. Mimo continues to raise the bar, introducing the 7” monitor with a VESA mount. In addition to the handy, sturdy VESA mount for wall, pole, and other elevated display configurations, the UM-760CF includes the same great features our customers have come to love. This lightweight display measures less than an inch thick and weighs less than a pound. It has it all, including the responsiveness of multi-point capacitive touch. The 7” VESA USB capacitive touchscreen display is well-suited for retail, consumer, industrial, manufacturing, or hospitality markets.

  • A single USB connection supplies video, touch, and power thanks to DisplayLinkTM technology. Never again worry about a separate AC power supply.
  • Features sturdy VESA 75 mm rear mount
  • Suited in retail POS environments as a secondary customer-facing display

Here is a small sampling of the applications enhanced by the Mimo 7” VESA display:

  • POP/POS
  • Secondary screen for productivity
  • Gaming and entertainment
  • Light industrial shop-floor automation
  • Digital Signage
  • Video Conferencing

UM-760 Family

MODEL DESCRIPTION 2G REPLACEMENT
UM-760 Mimo 3G Non-Touch Slider, 1024x600 UM-710
UM-760R Mimo 3G Resistive Touch Slider, 1024x600 UM-720S
UM-760C Mimo 3G Capacitive Touch Slider, 1024x600 with a modern zero-bezel tablet-like design New
UM-760C-SMK 7" Capacitive Touch Display, USB with Speaker, Metal Back and Adjustable Brightness New
UM-760CH-SMK 7" Capacitive Touch Display, HDMI with Speaker, Metal Back and Adjustable Brightness New
UM-760-OF Mimo 3G Non-Touch Open Frame, 1024x600 UM-710-OF
UM-760RK-OF Mimo 3G Resistive Touch Open Frame, 1024x600 UM-720S-OF
UM-760R-OF NRFND - Mimo 3G Resistive Touch Open Frame, 1024x600 UM-720S-OF
UM-760C-OF Mimo 3G Capacitive Touch Open Frame, with a modern zero-bezel tablet-like design New
UM-760F Mimo 3rd Gen non-touch VESA New
UM-760RF Mimo 3G Resistive VESA Mount, 1024x600 UM-720F
UM-760CF Mimo 3G Capacitive VESA Mount, 1024x600 with a modern zero-bezel tablet-like design New

USB Extender

In some applications, it is necessary to install or mount the display a long distance from your computing devices. Is there a way to do this effectively without having to route AC power to your wall or table installation? Check out our USB extender. This plug-and-play, two-port USB 2.0 high-speed extension solutions gives a fast connection over Cat 5e cabling. It delivers Power over Twisted Pair to power the remote side from the source side, eliminating the need for AC power. Deployment has never been easier for industrial, medical, commercial, and other applications where the display is located away from the source computer.

Additional Accessories:

Get the most out of your display with these convenient accessories direct from Mimo Monitors:

Resistive Touch Screen Stylus for Monitors

Small Case specifically designed for 7” screens

Raspberry Pi Support

To configure your display with Raspberry Pi, please visit this page for the 7” Monitors: https://www.mimomonitors.com/pages/using-mimo-with-raspberry-pi

Mac OS X Touchscreen Support

To support touchscreen functionality, an additional driver is required for Macintosh computers (Intel-based only). Click here to download the driver required for using the Mimo 760CF with Mac OS.

Product Specs



Display Size
7 inch
Display Resolution
1024 x 600 (WSVGA) LCD
Brightness
250cd/m2
Contrast Ratio
700:1
Pixel Pitch
0.15 (H) x 0.15 (V)
View Angle
75/75/70/75(L/R/U/D)
Connections
USB
Operating Temperature
-20 to 60c
Mount
VESA-75mm
Power Consumption
4W
Dimensions
185.14mm x 127.14mm x 31.55mm
Warranty
1 Year

Features
  • Utilizes Displaylink for power, touch and video over single USB connection
  • Capacitive Multi-point Touch Screen
  • Surface treatment: Hard coating (3H), anti-glare

Regulatory Certifications
FCC, CE, ROHS, KC
TAA Compliant

Download this model's product sheet (PDF)

Download this model's 2D Drawing (PDF).
